AB8651T 2 Channel UHF Wireless Microphone

UHF band signal transmission, frequency range: 500MHz–900MHz;
with ≥200 selectable channels per channel, 250kHz stepping per channel, and 49.75MHz per channel
Support simultaneous use of ≥40 units (i.e., 40 receivers and 80 transmitters)
Built-in high-efficiency noise suppression circuit with excellent anti-howling effect;
The receiver is fitted with 2 rubber receiving antennas on the rear to enhance signal reception
The rear panel is equipped with ≥2 balanced outputs and 1 mixed unbalanced output
Same transmitter can work interchangeably across 400 channels on two channels
Ultra-quiet tactile switch, press and hold for 2 seconds to power on and enter working mode
The handheld transmitter features RF power selection
Equipped with 2 head-worn microphones and bodypack transmitters.

Receiver Specifications
Oscillation Mode	Phase-Locked Loop Frequency Synthesis (PLL Synthesized）
Frequency Range UHF	500MHz～900MHz
Frequency Stability	±0.001%
Modulation Mode	FM
Signal-to-Noise Ratio	>60dB
Total Harmonic Distortion	<0.5% @ 1kHz
Sensitivity	1.2μV @ S/N=12dB
Power Supply: DC	12V～17V
Audio Output (Independent)	0～400mV
Audio Output (Mixed)	0～300mV
Transmitter Specifications
Power Supply: DC	4.5V (1.5V AA × 3)
Microphone Current Consumption	100mA /1000mA
Carrier Frequency: UHF	500MHz～900MHz
Frequency Stability	±0.001%
Maximum Frequency Deviation	±30kHz
Signal-to-Noise Ratio	>60dB
Adjacent Channel Rejection	>80dB
Dynamic Range	≥100dB
Type	Capacitive
Polar Pattern	Unidirectional
Frequency Response	40Hz～20kHz
Microphone Sensitivity	-43±3dB @ 1kHz
