Wall Mount Speaker
Ideal for small, medium, and large spaces, such as shopping malls, supermarkets, exhibition centers, and auditoriums, School gymnasiums, playgrounds, and campus-wide PA systems， Outdoor squares, parks, scenic areas, and large parking lots. Etc.,
IP66, all weather speaker for indoor and outdoor use
With power tap for 70V/100V and 8Ω
Rated output power 20W/40W
1×5", 1×6.5" or 1×8" for woofer and 1×1" for tweeter
Quick installation with water-proof brackets
Fashionable appearance with extraordinary sound quality
Ideal for schools, offices, hotels, stations and meeting rooms public address system
| Model | WS-620 | WS-630 | WS-640 |
| Tweeter | 1" (25 mm) Silk soft dome | 1" (25 mm) Silk soft dome | 1.1" (28 mm) Silk soft dome |
| Woofer | 4" (100 mm) Graphite Cone, Rubber Surround | 5" (125 mm) Graphite Cone, Rubber Surround | 6.5" (165 mm) Graphite Cone, Rubber Surround |
| Frequency Range (±3dB) | 70 Hz – 20 kHz | 65 Hz – 20 kHz | 52 Hz – 20 kHz |
| Power Handling (RMS) | 40W Program, 20W (IEEE 219) | 60W Program, 30W (IEEE 219) | 60W Program, 40W (IEEE 219) |
| Sensitivity | 83 dB | 85 dB | 87 dB |
| Power Taps | 8Ω, 0, 20W, 10W, 5W, 2.5W | 8Ω, 0, 30W, 15W, 7.5W, 3.75W | 8Ω, 0, 40W, 20W, 10W, 5W |
| Impedance | 8 Ω (common for all models) | ||
| Termination | Standard rotary connector (common for all models) | ||
| Included Accessories | Brackets, Waterproof cover, Grille (common for all models) | ||
| Dimensions (H×W×D) | 235.5 × 146.5 × 140.5 mm | 269 × 168 × 165.5 mm | 309 × 196 × 183 mm |
| Certifications | IP66 (common for all models) | ||
| Cabinet Material | PP (Polypropylene) (common for all models) | ||
